Model

Rotary Table Size (in)

Applicable Diameter of Tubular (in)

Rated Capacity (t)

Working Pressure (MPa)

Max Pressure (MPa)

PS175

17-1/2

2-3/8~5-3/4

150

0.6~0.8

1

PS205

20-1/2

2-3/8~5-3/4

250

0.6~0.8

1

PS275

27-1/2

2-3/8~9-7/8

350

0.6~0.8

1

PS375

37-1/2

2-3/8~14

500

0.6~0.8

1

PS16

27-1/2，37-1/2,49-1/2

3-1/2~7-3/4

500

0.6~0.8

1

PS Portable

23,27-1/2,7-1/2,49-1/2

Four Pin driving rotary table

2-3/8~5-1/2

250

350

0.6~0.8

1

 PS slope collar

apply for slope collar

2-7/8~13-3/8

250

0.6~0.8

1

PS 560

560mm Drift diameter

1.9~7

350

0.6~0.8

1

QW275

27-1/2

3-1/2~6-3/8

350

0.6~0.8

1

QW375

37-1/2

3-1/2~6-3/8

450

0.6~0.8

1
